Auto Digital Creaser & Folder (YD-5375BFII)

loading

Share to:
  • YD-5375BFII
  • Artter
** The creaser will handle most types of paer /card from 100 to 350 GSM
** Feeding the manual feed unit is done by stacking the card in a shingle pile and feeding successively the sheets
** Feeding by the auto feeder can be done continuously loading the pile
** Setting up the machine is done by the easy to use LCD screen where all the main parameters can be loaded in seconds
** Fold roller grap adjustable by easy use knob
** Large reception tray with magnetic stops for crease only (folder by pass)
** Jam detector
** Touch screen control
** The creaser can optionally by fitted with perforating wheels mounted on the output shafts ** Optional perforating wheels on the outfeed (on one else can do that)
** Optional infeed tray extension for sheets up to 600mm length
** Technical menu
** Stacking the card in single by speed adjustable stacker
** You can start by buying the base manual unit, add the auto feed system, pump and stand later on.

System combination:
A) Auto feed or hand feed
B) Feed-crease
C) Feed-fold
D) Feed-crease-fold
